Introduction

Sealey Industrial High Velocity Floor Fan 20″ 230V

High velocity fan suitable for movement of huge volumes of air.

Features 3-speed settings for choice of airflow and tilting blade cradle.

Fully guarded blades with large diameter base for safety and added stability.

Mains cable storage keeps it tidy when not in use.

Maximum airflow up to 110m/min.

Suitable for industrial, commercial, agricultural, workshop and showroom applications.

Specification:

• Model No HVF20
• Brand: Sealey
• Current: 0.5A
• Fan Diameter: 550mm(20″)
• Maximum Airflow: 110m/min(3900cfm)
• Nett Weight: 6.03kg
• Power: 105-115W
• Maximum Flow Rate (F): 160.35 m/min
• Fan Power Input (P): 105.5W
• Service Value (SV): 1.52 (m/min)/W
• Standby Power Consumption (Psb): 0.0W
• Seasonal Electricity Consumption (Q): 33.76kWh/a
• Fan Sound Power Level (Lwa): 78.26dB(A)
• Maximum Air Velocity (c): 3.31m/s
• Speed Range: 1100/1225/1350rpm
• Speeds: 3
• Supply: 230V

Product Guarantee: 1 Year
Catalogue Page: Page 1271

Downloadable Files:

• Instructions: View Here
• Parts Diagram: View Here
